Bandit Micro ExpressLRS 915MHz RF Module

After extensive research and collaboration with the ExpressLRS team, we are thrilled to unveil the all-new Bandit Micro ExpressLRS RF Module. This cutting-edge module represents the culmination of our efforts…

Specifications

After extensive research and collaboration with the ExpressLRS team, we are thrilled to unveil the all-new Bandit Micro ExpressLRS RF Module. This cutting-edge module represents the culmination of our efforts to deliver unparalleled performance, reliability, and low-latency links for any application. Features Up to 1 Watt power output Packet rates up to 200Hz Optimized circuitry for ultra-low power consumption Built-in TCXO oscillator Low noise, high comfort High contrast OLED display Innovative convection cooling design Wifi and Bluetooth support Built-in ExpressLRS backpack 5 Directional nav key 915/868MHz T Antenna included With the Micro connector, support TX16S MKII, Boxer, and TX12 MKII radio Specifications Item: Bandit Micro ExpressLRS RF Module Regulatory Domain: FCC915 MCU: ESP32(main), ESP8285(aux, as ESP backpack) RF Chip: SEMTECH SX1276 Refresh Rate Min/Max: 25Hz/200Hz Micro standard 5pin connector Built-in OLED screen XT30 Power Supply Voltage: DC 6V ~ 16.8V Weight: 78.0grams (with T antenna) Dimension: 64.1*49.6*34.1mm Keep Your Cool! With its innovative convection cooling system and built-in turbo fan, the Bandit Micro ExpressLRS module ensures optimal temperature control and operates with minimal noise. The Bandit Micro form factor is ready to go with our TX16S MKII , Boxer , TX12 MKII and other radios with a Micro Module bay. Intuitive Control at Your Fingertips The Bandit Micro ExpressLRS features an OLED display, a five-directional navigation key, ensuring an unparalleled RC experience. Versatile Antenna Options for Diverse Applications The Bandit Micro ExpressLRS comes equipped with a RadioMaster T Antenna for general-purpose use. The RadioMaster Moxon antenna is available separately for situations where a more focused, directional pattern is needed to achieve a stronger, more reliable link. This versatility allows you to tailor your setup to a wide range of operational scenarios, whether for everyday use or demanding professional applications. But wait.. there’s more! The Bandit Micro has UART solder pads on the PCB and may also be repurposed as a receiver! That’s right, you can use the Bandit Micro as a 1000mW telemetry receiver for an incredibly reliable link and high-quality telemetry in the most demanding applications. The Ideal Solution for Demanding Applications Whether you’re an experienced operator or a professional requiring precise, dependable control systems, the Bandit Micro ExpressLRS RF Module is the perfect choice for mission-critical use. Its unmatched performance, rugged construction, intuitive controls, and versatile antenna options make it an indispensable tool for those seeking the highest standard in reliable, high-quality RF technology. Dimensions Bandit Series Bandit ExpressLRS RF Module Bandit Micro ExpressLRS RF Module Bandit Nano ExpressLRS RF Module Bandit BR1 Receiver Bandit BR3 Receiver Bandit MOXON Antenna Bandit T Antenna UFL 915Mhz T & Y Antenna for BR Series Receivers Package Includes 1 * Bandit Micro ExpressLRS RF Module 1 * 900Mhz T Antenna 1 * Manual Bandit Micro is installed with ExpressLRS as standard. ExpressLRS is an open-source, high-performance radio control link that delivers exceptional range and low-latency communication using advanced LoRa technology. It’s highly customizable and perfect for RC enthusiasts looking for reliability and efficiency. Pair your ExpressLRS with Radiomaster’s top-tier transmitters and receivers. Radiomaster products are designed to maximize the benefits of ExpressLRS, offering state-of-the-art performance for your RC adventures. Upgrade your RC experience with the unbeatable combination of ExpressLRS and Radiomaster—engineered for excellence and tailored for you. Find out more about ExpressLRS here Bandit Micro is now compatible with mLRS! The mLRS project offers an open-source, high-performance radio system based on LoRa technology, operating at 2.4 GHz, 915/868 MHz, and 433 MHz/70 cm, designed to deliver a secure, reliable, and robust link under any conditions. mLRS is designed with MAVLink and MSP optimization in mind, while also providing a transparent serial link, making it suitable for a wide range of applications. Its design ensures the strongest possible signal integrity while maintaining a relatively high data rate, balancing performance and reliability without compromise. Find out more about mLRS here Visit the online mLRS Web Flasher here
