GEPRC 868MHz/915MHz 2.4G Tri-Band Stick Antenna

Summary The GEPRC 868MHz/915MHz/2.4GHz tri-band stick antenna features a PCB design with linear polarization for omnidirectional signal reception. It maintains strong connectivity during dynamic flight maneuvers. With excellent cross-polarization suppression,…

Specifications

Summary The GEPRC 868MHz/915MHz/2.4GHz tri-band stick antenna features a PCB design with linear polarization for omnidirectional signal reception. It maintains strong connectivity during dynamic flight maneuvers. With excellent cross-polarization suppression, it performs well in high-interference environments, minimizing signal disruption. Features 1.Triple-band design, 868MHz covers 860-870MHz, 915MHz covers 900-930MHz, 2.4Gz covers 2400-2500MHz 2. Optimized for stronger signal reception at a vertical angle 3. Durable, low-drag oval shape with an injection-molded ABS shell 4. High-quality SMA connector minimizes signal loss 5. Each antenna undergoes testing with a spectrum analyzer to ensure VSWR compliance with standards Specifications Model: GEPRC 868MHz / 915MHz / 2.4GHz Tri-Band Stick Antenna 868MHz Center Frequency: 865MHz 915MHz Center Frequency: 915MHz 2.4Gz Center Frequency: 2450MHz Frequency Range: 868MHz / 915MHz / 2.4Gz Polarization: Linear 868MHz Gain: 2.8dBi 915MHz Gain: 2.82dBi 2.4Gz Gain: 2.97dBi VSWR: ≤1.5 868MHz Radiation Efficiency: 49% 915MHz Radiation Efficiency: 51% 2.4Gz Radiation Efficiency: 68% Cross-Polarization Suppression: -25dB Length: 172mm Antenna Type: PCB Weight: 11.2g Housing Material: ABS Connector: SMA Include GEPRC 868MHz / 915MHz / 2.4GHz Tri-Band Stick Antenna x1
