GEPRC Vapor-D6 HD O4 Pro FPV Drone

Summary The GEPRC team has redesigned the Vapor series for optimal compatibility with the DJI O4 Air Unit Pro VTX. New aluminum lens components and shock-absorbing silicone reduce vibrations, while…

Specifications

Summary The GEPRC team has redesigned the Vapor series for optimal compatibility with the DJI O4 Air Unit Pro VTX. New aluminum lens components and shock-absorbing silicone reduce vibrations, while the sharp new side panels give it a bold, mech-inspired look. The DJI O4 Air Unit Pro’s larger CMOS sensor enhances image detail and sensitivity, and the GEPRC-tuned PID settings ensure a smooth and immersive flight experience. Available in two models, Wide X and DC, to suit different flight needs. Feature DJI O4 Air Unit Pro features a powerful CMOS sensor for improved image clarity and enhanced light sensitivity. CNC aluminum lens housing for a durable, bold design. GEPRC SPEEDX2 E-series motors for smooth, powerful performance. Front lip design provides extra lens protection for confident flying. Wider 5mm carbon fiber arms for increased durability and a sleek build. Specifications Model: Vapor-D6 O4 Pro Frame: GEP-Vapor-D6 O4 Pro frame Wheelbase: 274.60 mm Top Plate: 2.0 mm Middle Plate: 2.0 mm Bottom Plate: 2.5 mm Arm Thickness: 5.0 mm FC: GEP-F722-HD v2 MCU: STM32F722 Gyro: ICM42688-P(SPI) Barometer: YES OSD: Betaflight OSD w/AT7456E ESC: TAKER H60_BLS 60A 4IN1 ESC VTX: DJI O4 Air Unit Pro Transmission Module Camera: DJI O4 Air Unit Pro Transmission Module Antenna: DJI O4 Air Unit Pro Antenna Connector: XT60 Optional GPS: GEP-M10 GPS 6-inch Motor: GEPRC SPEEDX2 2407E 1750KV 6-inch Propeller: HQprop 6X3.5X3 Vapor-D6 O4 Pro PNP Version Weight: 465 g±5g Receiver: PNP/GEPRC ELRS24/TBS Nano RX Recommended Battery: 6S LiPo1500mAh – 2000mAh Flight Time: 14-19 min Includes 1 x Vapor-D6 O4 Pro 2 x HQprop 6X3.5X3 2 x Battery anti-slip pads 1 x Spare screw pack 1 x Vapor side panel 2 x M20*250mm battery straps 1 x L-shaped screwdriver 1.5mm 1 x L-shaped screwdriver 2.0mm 1 x GoPro mount The spare screws include 6 x M3*10mm round head screws 6 x M3*8mm round head screws 2 x M3*6mm flat head screws 1 x M5*28mm thin head screw 1 x M5 flange nut 4 x M3 rivet nuts
