NEXUS Control System

The NEXUS Control System unit has been designed from the ground up based on the RF 2.0 reference design. All aspects of the NEXUS have been planned and tested for…

Specifications

The NEXUS Control System unit has been designed from the ground up based on the RF 2.0 reference design. All aspects of the NEXUS have been planned and tested for optimum performance and compatibility, ensuring the best out-of-the-box RF experience on the market today. Powered by the STM32F722 MCU and equipped with the highly accurate ICM42688P 6-axis MEMS motion tracker, the Nexus-X delivers precise control, seamless stabilization, and outstanding performance. Its integrated Black Box Onboard memory has been expanded to 256MB, enabling substantially longer data logging and the storage of detailed session records, facilitating easy tuning and performance optimization. Our Plug’n’Play solder-free RP3-H ExpressLRS receivers feature a locking connector system to ensure a stable connection between the control unit and receiver. DSM and S.BUS ports are also available for use with your selected receiver type. The NEXUS also features multi-function ports for future expansion. The NEXUS features a CNC machined aluminum case as standard, which looks great, protects the control unit, and dissipates heat for the F722 processor. After more than 12 months of dedicated R&D, the NEXUS has been rigorously tested, tuned, and refined—not only by our in-house developers but also by a skilled team of experienced users who joined our beta testing program. We extend our sincere thanks to the entire beta testing team—your insightful feedback and intensive real-world use have played a vital role in bringing the NEXUS to life! Built for exceptional performance, reliability, and seamless integration—take your setup to the next level with the NEXUS. Features The NEXUS Control System is designed from the ground up specifically for RF 2.0 Equipped with an advanced STM32F722 MCU and TDK 6-axis MEMS motion tracking device, which combines a 3-axis gyroscope and a 3-axis accelerometer Built-in Black Box: A large 128MB of onboard flash memory ensures you can log all your data for fine-tuning and adjustment Locking connector system compatible with our Plug’n’Play solder-free RP3-H ExpressLRS receivers, You can rest assured that there will be a stable connection between the control unit and the receiver (RP3-H not included) Features multi-function ports (UART) for future expansion The NEXUS Control System is compact and rugged. The CNC case not only protects the internal components but acts as a heat sink to help keep the electronics cool The NEXUS measures just 41mm x 25mm and is only 13mm high, making it a perfect fit for any size build. A variety of receivers are supported, including CRSF, ELRS, GHOST, S.BUS, SUMD, IBUS, XBUS, EXBUS, PPM, MSP, DSM2, DSMX, and F PORT The device has multiple independent power supplies that minimize noise when reaching 1.8V. Ultra light-weight and flexible USB-C extender cable is included to help in situations where the USB-C port may not be easy to reach. Made as light as possible because every gram counts and uses flexible silicone wires to prevent vibration transfer to the control unit RF Rescue function as a standard Specification Item: NEXUS Control System Firmware: RF 2.0 MCU: STM32F722RET6 Flash Memory (Black Box. IC): 128MB (W25N01GVZEIG) Barometer: SPL06-001 Uart: 6 – DSM[UART1], S.BUS[UART2], A-CRSF[UART4], PORT-B[UART6], PORT-C[UART3] Servo: 4 – S1, S2, S3, TAIL Rpm Sensor: 1 – FROM ESC FREQUENCY SENSOR Receiver Support: CRSF, ELRS, GHOST, S.BUS, SUMD, IBUS, XBUS, EXBUS, PPM, MSP, DSM2, DSMX Voltage Supply(DC): 5 – 12.6V A-B-C Serial Port Power Output: 5V – 2.0A DSM Serial Port Power Output: 3.3V – 0.5A Telemetry: S.BUS, HoTT, S.Port, MSP, EDGETX, ELRS Demensions: 41.3 X 25.4 X 13.1mm Weight: 16.8g A special thanks to the RF development team who without their hardwork and dedication this project would not have been possible. Learn more about RF HERE. Dimensions Overview Package Includes 1 * NEXUS Control System 3 * JST-GH 4 Wire pigtail cables 1 * JST-GH to Servo Plug (dupont 3 pin connector) 1 * Ultra light-weight and flexible USB-C extender 1 * Type C extension cable 3 * 3M double-sided mounting tape 2 * Heat shrink tubing
