Q10TIRM

GPS Location Calculation Series

Stabilizing the Q10TIRM is a highly optimized 3-axis camera gimbal with pinpoint-precise motor rotation with a control accuracy of ±0.01° powered by a dedicated processor. Q10TIRM uses a unique mechanically…

Specifications

:
:
Working voltage: 16V
Input voltage: 4S ~ 6S
Output voltage: 5V (connect with PWM)
Dynamic current: 600~1200mA @ 16V
Working environment temp.: -20℃ ~ +60℃
Output: micro HDMI(1080P 60fps) / IP (RTSP/UDP 720p/1080p 25fps/30fps)
Local-storage: SD card (Up to 512G,class 10, FAT32 format)
Photo storage format: JPG(1920*1080)
Video storage format: MP4 (1080P 30fps)
Card reading online: SMB read/ HTTP read
Control method: PWM / TTL / S.BUS / TCP(IP output)/UDP（IP output version）
Controllable Range: Pitch/Tilt: -45°～120°, Yaw/Pan: ±290° / ±360°*N (IP output version)
Vibration angle: Pitch/Roll: ±0.02°, Yaw：±0.02°
One-key to center: √
Imager Sensor: 1/3" Panasonic CMOS Sensor
Total pixel: 2.48M
Picture quality: Full HD 1080 (1920*1080)
Optical zoom: 10x, f = 5.1mm ~ 51mm
Digital zoom: 32x
Angle of View (D, H, V): D: 68°(Wide end) ~ 6.7° (Tele end)
Photo storage format: JPG(1920*1080/1280*720)
Video storage format: MP4 (1080P/720P 25fps/30fps)
Sync system: Progressive Scan
Sync. System Internal: Internal
S/N ratio: more than 50dB
Gain Control (AGC): Off / On
White balance: Auto / One Push / Manual / Indoor / Outdoor
Shutter speed: 1/30(25) ~ 1/30,000 sec
Get a Quote

Stabilizing the Q10TIRM is a highly optimized 3-axis camera gimbal with pinpoint-precise motor rotation with a control accuracy of ±0.01° powered by a dedicated processor. Q10TIRM uses a unique mechanically limited design and concealed wires to ensure more stable data transmission and greater durability. Vibration is eliminated using four damping balls and a lightweight damping board, creating seamlessly smooth video. 360°rotation remains possible through gimbal rotation. St
