★Skyzone RD945 5.8G 48CH Wireless Dual Receive FPV Receiver

Band/Channel Channel CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 Band (A) 5865 5845 5825 5805 5785 5765 5745 5725 Band (B) 5733 5752 5771 5790 5809 5828 5847 5866…

Specifications

Band/Channel Channel CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 Band (A) 5865 5845 5825 5805 5785 5765 5745 5725 Band (B) 5733 5752 5771 5790 5809 5828 5847 5866 Band (C) 5705 5685 5665 5645 5885 5905 5925 5945 Band (D) 5740 5760 5780 5800 5820 5840 5860 5880 Band (H) 5658 5695 5732 5769 5806 5843 5880 5917 Band (L) 5362 5399 5436 5473 5510 5547 5584 5621 SPECIFICHE RC832 Sensibilità <-90 dbm Canali 48 CH Alimentazione 12V DC Consumo max 200mAh Impedenza di ingresso dell'antenna 50 Ohm Connettore antenna RP SMA Guadagno dell'antenna 2 dbi Uscita Video x2 1.0Vp-p 75 Ω Uscita Audio 1.0Vp-p 10K Ω Segnale PAL / NTSC Dimensioni 80 * 65 * 15 mm Peso 85h
